vibrating table
Concrete Vibrating Table is mainly used for laboratory real shock forming concrete specimens and products. HZJ Series Concrete Vibration Table is mainly composed of the work table, frame, springs and other components integral vibrator.
Table with the bracket welded steel plate, vibrator motor and two same eccentric wheels, through the coupling of two hangers installed in the table below, a smooth tap.
Technical parameters:
| Model | NMC-05 | NMC-08 | NMC-10 | NMC-12 |
| Work table(mm) | 500*500 | 800*800 | 1000*1000 | 1200*1200 |
| Vibration frequency (times/min) | 960 | 960 | 960 | 960 |
| Amplitude(mm) | 0.3-0.6 | 0.3-0.6 | 0.3-0.6 | 0.3-0.6 |
| Vibrator power(KW) | 0.55 | 0.75 | 1.1 | 1.5 |
| Max load(kg) | 75 | 200 | 250 | 500 |
| Weight(kg) | 65 | 140 | 200 | 280 |
Nice Machinery is dedicated to solving the toughest screening, feeding and conveying problems while holding quality, safety and reliability paramount. We strive to consistently offer solutions that meet and often exceed customer expectations with regard to performance, dependability, ease of maintenance, price and delivery.
Nice Machinery offers the industry’s broadest range of vibrating sieves and particle separation equipment for wet, dry or slurry based material.Equipment serves the needs of all standard separation requirements and offers high capacity and efficiency with mesh size ranging from 10mm down to 25 micron for fine particle separation. Additional......[More>>]
